Hell'o and thanks for your interest in the European Feld Hell Net!
Why another Feld Hell Net?
This net is here to give hams operating out of Europe more opportunities to make QSO's in Hell Schreiber modes. I am aware that other Hell nets exist, but they are often out of reach or on bands that are not permitted to hams with a Novice license.
When: Every Saturday at 10:00/10AM ZULU TIME = 11:00 Amsterdam winter time / 12:00 Amsterdam summer time. 📅
You are welcome to start making QSOs. Initially we will work in FSK Hell-105/FM-Hell-105. Set transceiver to frequency listed below and waterfall +1500Hz. If the frequency is in use by other modes, move to a portion of free spectrum. We can make frequency and mode exceptions! Check hamspots.net and see all frequencies. Note that this net is on ZULU time, so when DST changes (winter/summer time) the net remains at 10:00Z. You can see the current ZULU time below.
When I am on-air you can see my station frequency in the live viewer below.
- 10.144 MHz USB odd weeks = 30m
- 14.088 MHz USB even weeks = 20m
Hamspots, check-ins, socialize
Compared to the US nets, this net is rather unorganized. There are no check-ins and there is no coordinating station. Whatever coordination we have is done on Hamspots. Hams not on Hamspots can use the live viewer below to find my frequency. I will post a message on https://hamspots.net/hell/ around the start time of the net including the frequency of the day. If you do not see my message, by all means add your own!
If you see my station you will notice I sometimes make QSO's very short, this is because I have a limited set-up. But I do like chatting without macros if conditions allows. If you have a better set-up or have favorable conditions, I encourage you to socialize and chat. But if you want to stick with just a basic QSO, that is fine too!
Reporting, feedback, questions
If possible log your QSO's on QRZ.com, LoTW, etc. You can reach out to me with your feedback and QSO success stories via email, find it on QRZ.com. For logging purpose the mode is FSKHELL. SWL reports welcome. You can see QSO screenshots from our net in the Hell QSO Gallery! For my other ham radio activities see pc1k.nl.
Live Hell Station Viewer, open in new window.
Extra: Sunday EU Hell Net 80m
Unrelated to the Saturday net (but in the same region) is the Hell net on Sunday at 16:30/4:30PM AMSTERDAM TIME. USB 3.5905 +1500 the operating mode is Feld Hell. This net is coordinated by PA0KDF (Koos) who serves as central controlling station. In contrast to the Saturday net, the frequency and mode are fixed. More information on this net and a list of all currently active Hell nets can be found at Non Stop Systems and the Sunday live viewer.
Hellschreiber discussion group
You can join FeldHellClub@groups.io where we discuss all matters relating to Hellschreiber. I will post QSO reports for the EU Feld Hell Net each week.
Mind your power!
FSK Hell-105 seems to be a bit more robust than Feld Hell, but it does have a 80% duty cycle, if your rig has heating issues, lower your power output! People using Signalinks in their setups will need to adjust them to handle the rapid off/on characteristic of Feld Hell. FSKH105 will work with PSK31 Signalink settings.
Can I join if I am outside of Europe?
Sure it is all about having fun and this net is for everyone!
My latest Hell QSO
Software
I recommend fldigi. Set the correct mode via the menu Op Mode->Hell->FSK Hell-105. CAT control is available via flrig. Make sure to check if your logging software logs the correct mode. If possible make sure to log as FSKH105. See below for in-depth explanation.
Software | OS | CAT | Log |
---|---|---|---|
Fldigi | Linux, Mac, Windows | yes | yes |
MultiPSK | Windows | yes | yes |
IZ8BLY Hellschreiber | Windows | no | no |
Logging HELL mode
When I started the EU Hell Net I found inconsistencies in how HELL is logged. This was due to issues in the ADIF standard and FlDigi. The ADIF standard supports MODE and SUBMODE fields for all Ham radio modes. Going forward Feld Hell is MODE HELL and no submode. FSK Hell-105 is MODE HELL and SUBMODE FSKH105. The way MODE and SUBMODE is implemented differs per application. But an ADIF compliant implementation does not seem to exist.
The best thing you can do is log Feld Hell as HELL and FSK Hell-105 as FSKH105. Since almost no application implements submode, you can put FSKH105 in the mode field. As of November 30th 2024 this is supported in qrz.com and fldigi. If you are interested in keeping track of the actual mode you used in a QSO, check and manually edit the QSO record in your QRZ.com logbook, if needed, so it reflects the correct mode. It appears QSO confirmations do not care about submode. Small bug in QRZ.com when exporting logbook to LoTW make sure to export the full logbook via 'properties' button. If you select QSO's in the list view and export to LoTW, it does not work.
Feld Hell Club
This net is an independent effort, but I have had help from the Feld Hell Club starting it up. If you like the Hell modes, consider becoming a Club member, it's free and they have a great membership certificate!
Hell frequencies
If you are using software such as Fldigi, you can set your transceiver to the frequency (1). And click the waterfall at 1500 (2). This will make you work on the actual frequency (3). If you are using different software or a hardware Feld Hell machine you should refer to the actual frequency (3).
Band | Transceiver (1) | Waterfall (2) | Actual frequency (3) | CEPT lic. | WARC band | Comments |
---|---|---|---|---|---|---|
🌐 80m | 3.5905 MHz USB | 1500 Hz | 3592.000 kHz USB | F | Sunday EU Net | |
60m | 5.354 MHz USB | 1500 Hz | 5355.500 kHz USB | F | Max. 15W EIRP | |
40m | 7.045 MHz USB | 1500 Hz | 7046.500 kHz USB | F,N | Preferred | |
40m | 7.096 MHz USB | 1500 Hz | 7097.500 kHz USB | F,N | QRM fallback | |
🌐 30m | 10.144 MHz USB | 1500 Hz | 10145.500 kHz USB | F | ⭐ | Saturday EU Net odd weeks starts here |
🌐 20m | 14.088 MHz USB | 1500 Hz | 14089.500 kHz USB | F,N | Saturday EU Net even weeks starts here | |
17m | 18.105 MHz USB | 1500 Hz | 18106.500 kHz USB | F | ⭐ | |
15m | 21.087 MHz USB | 1500 Hz | 21088.500 kHz USB | F | ||
12m | 24.924 MHz USB | 1500 Hz | 24925.500 kHz USB | F | ⭐ | Possible WSPR operations |
10m | 28.080 MHz USB | 1500 Hz | 28081.500 kHz USB | F,N |
Why these frequencies?
(a) Compliance with IARU band plans for all regions. (b) Use 'narrow band mode' sections of the spectrum when possible. (c) Avoid built-in frequencies for CW, PSK31 in Fldigi and built-in frequencies for all modes in WSJT-X. (d) Align with the frequencies used by the Feld Hell Club. In addition it has been verified against the law in The Netherlands. I have chosen 20m and 30m as our starting point because this net is about making Hell accessible, and not so much about making long distance connections. Factors considered include: days and times other Hell nets operate, frequencies that can be used by Novice and my own QSO's. Based on this it seems 20m and 30m are our best options. Since 30m is not allowed for Novice and 20m can be over crowded, I opted for going with 20m on even weeks and 30m on odd weeks. It is not written in stone and we can change this as time goes by if needed.
- Feld Hell Club frequencies
- Non Stop Systems frequencies
- IARU Band Plan region 1
- IARU Band Plan region 2
- IARU Band Plan region 3
- Hellschreiber bandwidth
- Dutch law
If you are interested in customizing Fldigi with custom Hell Fonts, include the Hell operating frequencies and more, take a look at: PC1K Fldigi customization.
Hope to see you in Hell, 73 de PC1K!
